BC plastic free roller conveyor for flow rack,pallet roller track with 15mm dia.42mmwidth rollers

Product Description:

Production Description

BC-8B-60 plastic roller track
The advantage of Plastic roller tracks:
A. Mainly used in tranporting, storage system supporting products, can be used as slippery course,
protect column, guiding device.
B. Adopt the high quality thermoplastic plastic, has small friction coefficient, impact resistance, long life, acid porrf alkaline, resistant to moisture wet, etc.
C. Usually in depth direction every 600mm to 800mm installed a root support beam to increase the stiffness.
D. Rolling performace good, the cost is low.

Product Name	BC-8B-60
Wheel Material	ABS or PE
Wheel Size	OD15mm*W42mm
Frame Material	galvanized carbon steel
Frame Size	W60mm*H25mm
Pitch	16mm 62wheels/m
Load capacity	500kg/m

Products Show

Model	BC-8B-60	total height(H)	30mm
Wheel width(W)	42mm	wheel material	ABS or PE
Wheel diameter(D)	15mm	Frame material	galvanized carbon steel
Frame width(W1)	60mm	pitch	16mm 62wheels/m
Frame height(H1)	25mm	load capacity	500kg/m

Packing & Delivery

wooden case with bubble roll
