BC light duty stainless steel free rollers for roller conveyor,replacement roller with 19mm dia.1.2mm wall tubes

Product Description:

Production Description

How to order rollers?
1. Tell us the roller length: the length of the items plus 50mm~150mm, please.
2. The thickness and diameter of rollers: Average the weight of item to the touched rollers,
calculate the loading weight of each roller, then decide it. At least 3 rollers to support the
conveying item at any time to ensure the steady working all the time.
3. The material and surface treatment: depending on the different working environment,
decide the material and surface treatment (such as galvanized, stainless steel, chem-black or rubber lagging).
4. The assembly method: According to the conveyor system requirements to choose the
assembly method, such as spring shaft, female threaded, male threaded, mortise, half mortise,
hexagon shaft, pin shaft and hollow tube shaft.

BR-1912 replacement roller for conveyors
Replacement Rollers or Loose Rollers are offered in a variety of sizes. Typically identified by
the roller tube diameter and wall thickness, most are available with a variety of bearing
options including precision, semi-precision and non-precision bearings. Roller surfaces
include: Standard Carbon Steel with an optional orange polyurethane roller cover or
a galvanized steel roller.

BR- 1210 - 300W - 313EL - 330L
A B C D E

A.Roller size 12mm dia.1.0 wall
B.Tube width 300mm
C.Mounting dimension 313mm
D.Total width(tube+mounting+shaft) 330mm

Product Name	BR-1912
Roller Material	stainless steel or carbon steel
Roller Construction	Round tube, 19mm Diameter, 1.2mm wall tubes
Roller surface treatment	standard is galvanized
Tube width	50~500mm
Bearing	Standard Non-precision. Optional Semi-precision and Precision bearings
Axle retention	Standard is hollow tube shaft
