BC plastic skate wheel rail with 38mm dia.25mm width wheels,Placon roller rail for FIFO flow rail

Product Description:

Production Description

BC-7A-44 skate roller tracks
The advantage of Plastic roller tracks:
A. Mainly used in tranporting, storage system supporting products, can be used as slippery course,
protect column, guiding device.
B. Adopt the high quality thermoplastic plastic, has small friction coefficient, impact resistance, long life, acid porrf alkaline, resistant to moisture wet, etc.
C. Usually in depth direction every 600mm to 800mm installed a root support beam to increase the stiffness.
D. Rolling performace good, the cost is low.

Product Name	BC-7A-44
Wheel Material	ABS or PE
Wheel Size	OD38mmW25mm or 15mm26mm
Frame Material	Aluminum Alloy
Frame Size	W44mm*H33mm
Pitch	45mm 22wheels/m
Load capacity	80kg/m

Products Show

Model	BC-7A-44	total height(H)	44mm
Wheel width(W)	25mm	wheel material	ABS or PE
Wheel diameter(D)	38mm	Frame material	Aluminum Alloy
Frame width(W1)	44mm	pitch	45mm 22wheels/m
Frame height(H1)	33mm	load capacity	80kg/m

Packing & Delivery

wooden case with bubble roll
