BC plastic skate wheel conveyor,plastic roller tracks with Aluminum channel frame

Product Description:

Production Description

The advantage of Plastic roller tracks:
A. Mainly used in tranporting, storage system supporting products, can be used as slippery course,
protect column, guiding device.
B. Adopt the high quality thermoplastic plastic, has small friction coefficient, impact resistance, long life, acid porrf alkaline, resistant to moisture wet, etc.
C. Usually in depth direction every 600mm to 800mm installed a root support beam to increase the stiffness.
D. Rolling performace good, the cost is low.

Product Name	BC-1A-30
Wheel Material	PE
Wheel Size	OD13mmW14mm or 28mm14mm
Frame Material	Aluminum Alloy
Frame Size	W30mm*H22mm
Pitch	15/30/45mm 66/33/22wheels/m
Load capacity	40kg/m

Products Show

Model	BC-1A-30	total height(H)	24mm
Wheel width(W)	14mm	wheel material	PE
Wheel diameter(D)	13mm	Frame material	Aluminum Alloy
Frame width(W1)	30	pitch	15/30/45mm 66/33/22wheels/m
Frame height(H1)	22	load capacity	40kg/m

Packing & Delivery

wooden case with bubble roll
