    BC Placon skate wheel conveyor,plastic flange wheel conveyor with 32mm dia.22mm width wheels
      BC Placon skate wheel conveyor,plastic flange wheel conveyor with 32mm dia.22mm width wheels

    Product Description:

    Production Description




    BC-3A-38 skate wheel conveyor
    The advantage of Plastic roller tracks:
    A. Mainly used in tranporting, storage system supporting products, can be used as slippery course,
    protect column, guiding device.
    B. Adopt the high quality thermoplastic plastic, has small friction coefficient, impact resistance, long life, acid porrf alkaline, resistant to moisture wet, etc.
    C. Usually in depth direction every 600mm to 800mm installed a root support beam to increase the stiffness.
    D. Rolling performace good, the cost is low.

    Product Name
    BC-3A-38
    Wheel type
    skate wheel or flange wheel
    Wheel Material
    ABS or PE
    Wheel Size
    OD32mm*W22mm
    Frame Material
    Aluminum Alloy
    Frame Size
    W38mm*H35mm
    Pitch
    41mm  24wheels/m
    Load capacity
    70kg/m


    Products Show










    Packing & Delivery

    wooden case with bubble roll
