BC plastic wheel conveyor with 26mm dia.8mm width wheel

Product Description:

Production Description

BW-2608PS-1000L-30P skate wheel conveyor
Wheel Conveyors or Skate Wheel Conveyors are an alternative version of non-powered roller conveyors.
In these conveyors, a series of wheels are mounted to a variety of conveyor rail shapes and with various
wheel patterns to configure conveyor lanes, either in horizontal push applications or on slight decline
angles for gravity flow solutions.
e.g:

BW - 2015 BS CR - 1000L - 30P
A B C D E F

A:THe structure of frame
B:Wheel diameter+wheel width
C:tpyes of wheel
BS-cutting wheel ,TS-pressed wheel ,RB-rubber coated,PS-resin wheel
D:Wheel surface treatment
Standard is galvanized,CR-chromed,N-nickel,SUS-stainless steel
E:roller track length
F:Pitch(distance between tow wheel)

Product Name	BW-2608PS-1000L-30P
Roller Material	POM
Bearing	standard is 608 bearing
Roller Size	OD26mmW8mmd6mm*L16mm
Frame Material	carbon streel or stainless steel
Frame surface treatment	powder painting
Frame Size	W18.8mm*H30mm
Thread	Pan Head or Hexagon Head
Pitch	30mm/35mm
Load capacity	25kg/pcs

Products Show

Model	BW-2608PS-1000L-30P	Wheel material	Polyformaldehyde
Roller diameter(D)	26mm	Frame material	carbon steel or stainless steel
Roller width(W)	8mm	Roller pitch	30mm/35mm
Frame width(W1)	18.8mm	Load capacity	25KG/pcs
Frame width(W2)	7mm	Conveyor length	2000mm
Frame high(H1)	25mm	Special design	Yse
Frame high(H)	30mm	Warranty	12month
Bending thickness(t)	1.5mm
